Critical IoT connectivity: Ideal for time-critical communications

Critical Internet of Things (IoT) connectivity is ideal for a wide range of time-critical use cases across most industry verticals, and mobile network operators are uniquely positioned to deliver it.

Ericsson CTO Erik Ekudden’s view on the benefits of critical IoT connectivity

Critical Internet of Things (IoT) connectivity is an emerging concept in IoT development that enables more efficient and innovative services across a wide range of industries by reliably meeting time-critical communication needs. Mobile network operators (MNOs) are in the perfect position to enable these types of time-critical services due to their ability to leverage advanced 5G networks in a systematic and cost-effective way.

This Ericsson Technology Review article explores the benefits of Critical IoT connectivity in areas such as industrial control, mobility automation, remote control and real-time media. It also provides an overview of key network technologies and architectures. It concludes with several case studies based on two deployment scenarios – wide area and local area – that illustrate how well suited 5G spectrum assets are for Critical IoT use cases.

Ericsson Technology Review logo

June 2, 2020

Authors: Fredrik Alriksson, Lisa Boström, Joachim Sachs, Y.-P. Eric Wang, Ali Zaidi

Download article as pdf

5GC – 5G Core
AAS – Advanced Antenna System
AGV – Automated Guided Vehicle
AR – Augmented Reality
CA – Carrier Aggregation
DC – Data Center
DL – Downlink
E2E – End-to-End
eMBB – Enhanced Mobile Broadband
FDD – Frequency Division Duplex
IoT – Internet of Things
MNO – Mobile Network Operator
NG-RAN – Next Generation RAN
NPN – Non-Public Network
NR – New Radio
PLC – Programmable Logic Controller
RTT – Round-Trip Time
TDD – Time Division Duplex
TSN – Time-Sensitive Networking
UE – User Equipment
UL – Uplink
URLLC – Ultra-Reliable Low-Latency Communication
VR – Virtual Reality

Critical Internet of Things (IoT) connectivity is ideal for a wide range of time-critical use cases across most industry verticals, and mobile network operators are uniquely positioned to deliver it.

Cellular Internet of Things (IoT) is driving transformation across various sectors by enabling innovative services for consumers and enterprises. There are currently more than one billion cellular IoT connections, and Ericsson forecasts that there will be around five billion connections by 2025 [1].

As 5G deployments gain momentum globally, enterprises in almost every industry are exploring the potential of 5G to transform their products, services and businesses. Since the requirements for wireless connectivity in different industries vary, it is useful to group them into four distinct IoT connectivity segments: Massive IoT, Broadband IoT, Critical IoT and Industrial Automation IoT [2].

While Massive IoT and Broadband IoT already exist in 4G networks, Critical IoT will be introduced with more advanced 5G networks. Industrial Automation IoT, the fourth segment, includes capabilities on top of Critical IoT that enable integration of the 5G system with real-time Ethernet and time-sensitive networking (TSN) used in wired industrial automation networks.

Critical IoT addresses the time-critical communication needs of individuals, enterprises and public institutions. It is intended for time-critical applications that demand data delivery within a specified time duration with required guarantee (reliability) levels, such as data delivery within 50ms with 99.9 percent likelihood (reliability).

Critical IoT is a paradigm shift from the enhanced mobile broadband (eMBB) connectivity, where the data rate is maximized without any guarantee on latency [3]. Many industry sectors have already started piloting time-critical use cases.

Time-critical use cases

The majority of time-critical use cases can be classified into the following four use case families:

  • Industrial control
  • Mobility automation
  • Remote control
  • Real-time media

Each family is relevant for multiple industries and includes a wide range of use cases with more or less stringent time-critical requirements, as shown in Figure 1.

Furthermore, there are three main network deployment scenarios depending on the coverage needs of time-critical services in different industries:

  • Local area
  • Confined wide area
  • General wide area
Figure 1: Examples of use cases enabled by Critical IoT

Figure 1: Examples of use cases enabled by Critical IoT

Local-area deployment includes both indoor and outdoor coverage for a small geographical area such as a port, farm, factory, mine or hospital. Confined wide-area deployment is for a predefined geographical area – along a highway, between certain electrical substations, or within a city center, for example. General wide-area deployment is about serving devices virtually anywhere.

Common to all time-critical use cases is the fact that the communication service requirements depend on the dynamics of the use case and the application implementation. A highly dynamic system requires faster control with shorter round-trip times (RTTs), while a slower control loop is sufficient for a system that operates more slowly.

Various factors – such as device processing capabilities, the processing split between the device and the application server, the application’s ability to extrapolate and predict data in case of missing packets, rate adaptivity and which codecs are used – impact both the application RTT and the latency requirements on the communication network.

Industrial control includes a very broad set of applications, present in most industry verticals [4]. These applications typically consider late messages as lost. Process monitoring, controller-to-controller communication between production cells and some control functions for the electricity grid are examples of use cases with modest time-criticality, while use cases such as closed-loop process control and motion control have very stringent requirements.

Mobility automation refers to the automation of control loops for mobile vehicles and robots. Examples of the least time-critical use cases in this category include the relatively self-sufficient automated guided vehicles (AGVs) equipped with advanced on-board sensors that are used for transportation in ports and mines. Infrastructure-assisted vehicles such as fast-moving AGVs
in a warehouse and collaborative maneuvering on public roads are examples of more time-critical mobility automation use cases, while the collaborative mobile robots used in flexible production cells represent an even higher degree of time-criticality.

Remote control refers to the remote control of equipment by humans. The ability to remotely control equipment is an important step in the evolution toward autonomous vehicles (to take temporary control of a driverless bus in scenarios not covered by its own automation functions) and for flying drones beyond visual line-of-sight.

Remote control can also improve work environments and productivity by moving humans out of inconvenient or hazardous environments – remote-controlled mining equipment [5] is one example. Such solutions also offer the benefit of providing enterprises with access to a broader workforce.

The communication service requirements for remote control depend on how fast the remote environment changes, the required precision of the task and the required QoE. Control-loop latency and audio/video quality are important factors for QoE and the ergonomics for the remote operator. Haptic feed-back and augmented reality (AR) can be used to further improve the operator QoE and task precision, and will make the acceptable latencies even stricter.

Real-time media comprises use cases where media is produced and consumed in real time, and delays have a negative impact on QoE. Mobile applications for gaming and entertainment, including AR and virtual reality (VR), are common, with processing and rendering done locally in the device. Time-critical communication will make it possible to offload parts of the processing and rendering to the cloud [6], thereby improving the user experience and enabling the use of more lightweight devices (head-mounted, for example).

Time-critical communication can enable cloud gaming over cellular networks as well as new applications in sectors such as manufacturing, education, health care and public safety. It is expected to drive more widespread use of mobile AR and VR. Advanced media production (such as real-time production of live performances) with its strict delay and synchronization requirements, is another area where time-critical communication can enable new use cases.

Time-critical use case trials

In partnership with leading industry partners and mobile network operators, Ericsson has trialed various Critical IoT use cases including:

Key network technologies and architectures

Achievable end-to-end (E2E) latencies depend on the available network and compute infrastructure, software features, and how the use case is implemented. In remote control, the physical distance between the remote operator and the teleoperated equipment is a physical property of the use case. In other use cases, the physical distance between end nodes can be reduced by distributed cloud processing, as in AR cloud gaming, where the AR overlay can be rendered in an edge cloud to limit interaction latencies. Network orchestration optimizes the placement of network and application functions to ensure efficient use of the compute and network infrastructure while restricting the transmission paths according to latency needs [7].

The 5G network comprises two functional domains: the next generation (5G) RAN (NG-RAN) and the 5G Core (5GC), which are built on an underlying transport network. All three – the NG-RAN, the 5GC and the transport network – contribute to the E2E reliability and latency, which is further affected by the device implementation.

The NG-RAN is deployed in a distributed fashion to provide radio coverage with good performance, availability and capacity. The 5GC provides connectivity of the device to the external services and applications. The network latency between the application and the RAN can be a major contributor to E2E latency.

Figure 2 provides examples of network architectures for low latency and/or high reliability, and illustrates the effect of moving the application closer to the device. If an application is hosted in a central national data center (DC), the transport network round-trip latency can be in the order of 10-40ms, depending on the distance to the DC and how well the transport network is built out. Transport latency can be reduced to 5-20ms by moving applications to a regional DC or even to 1-5ms for edge sites. For local network deployments with networking functions and applications hosted on-premises, transport latencies become negligible.

Figure 2: Examples of network architectures for low latency and/or high reliability

Figure 2: Examples of network architectures for low latency and/or high reliability

Control of the network topology and the transport latency can be achieved by placing virtualized core network functions for execution at any location within the distributed computing platform of the network. This software-based design provides flexibility in updating the network with new functionality and reconfiguring it according to requirements. In addition to running telecommunication functions, the distributed computing platform allows the hosting of application functions in the network [8].

Network slicing makes it possible to create multiple logical networks that share a common network infrastructure. A dedicated network slice can be created by configuring and connecting computing and networking resources across the radio, transport and core networks. By reserving resources, a high availability of time-critical services can be ensured and latencies for queuing can be avoided.

Network orchestration automates the creation, modification and deletion of slices according to a slice service requirement [2]. This can imply that compute locations are selected according to guaranteed resource availability and transport latency rather than the lowest compute costs, for example. 5G New Radio (NR) provides several capabilities for ultra-reliable low-latency communication (URLLC) [7, 9]. From the first NR standard release, the target has been to enable one-way latencies through the RAN of down to 1ms, where a timely data delivery can be ensured with 99.999 percent probability.

Features addressing low latency include ultra-short transmissions, instant transmission mechanisms to minimize the waiting time for uplink (UL) data, rapid retransmission protocols that minimize feedback delays from a receiver to the transmitter, instant preemption and prioritization mechanisms, interruption-free mobility and fast processing capabilities of devices and base stations.

Features addressing high reliability include a range of robust signal transmission formats. There are methods for duplicate transmissions to improve reliability through diversity, both within a carrier using transmissions through multiple antenna points, as well as between carriers through either carrier aggregation (CA) or multi-connectivity.

Advanced antenna systems (AAS) have tremendous potential to improve the link budget and reduce interference. The vendor-specific radio network configuration, algorithms for scheduling, link adaptation, admission and load control that are at the heart of NR make it possible to fulfill service requirements while ensuring an optimized utilization of available resources.

Support for highly reliable communication has also been addressed for the 5GC, by introducing options for redundant data transmission. Multiple redundant user-plane connections with disjoint routes and nodes can be established simultaneously. This may include the usage of separate user equipment (UE) on the different routes. 5G provides QoS, and by configuring a suitable QoS flow through the 5G system for transporting time-critical communication, queuing latencies due to conflicting traffic can be avoided by traffic separation with resource reservations and/or traffic prioritization.

For a time-critical communication service that is requested by a consumer, a data session with a suitable QoS flow profile is established, according to a corresponding service subscription. Larger customers, like an enterprise, are typically interested in connectivity for an entire device group. For this purpose, 5G has defined non-public networks (NPNs), which are real or virtual networks that are restricted for usage by an authorized group of devices for their private communication [10]. An NPN can be realized as a standalone network not coupled to a public network that is purpose-built to provide customer services at the customer premises.

Alternatively, an NPN may share parts of the network infrastructure with a public network, like a common RAN that is shared for private and public users. Beyond the shared RAN, the NPN may have a separate dedicated core network and local breakout – that is, it may be located on the customer’s premises with its own device authentication, service handling and traffic management. Finally, an NPN can be a network service that is provided by a mobile network operator (MNO) as a customer-specific network slice.

Some NPNs may be customized to provide dedicated functionality for industrial automation, including 5G-LAN services and Ethernet support, providing ultra-low deterministic latency, interworking with IEEE (the Institute of Electrical and Electronics Engineers) TSN, and time-synchronization to synchronize devices over 5G to a reference time [11, 12]. Enhanced service exposure of the 5G system makes it possible to better integrate 5G into an industrial system [13] by means of service interfaces for device management (device onboarding, connectivity management and monitoring, for example) and network management.

5G spectrum flexibility

5G NR allows MNOs to take full advantage of all available spectrum assets. NR can be deployed using the spectrum assets used for the LTE networks, either through refarming or spectrum sharing [14]. Most of the LTE spectrum assets are in the low and mid bands, which in the 5G era will continue to be used for wide-area coverage. Traffic growth will drive the need for increased network capacity throughout the 5G era.

Increased capacity can be achieved by adding more spectrum assets, densifying the network and/or upgrading capabilities at existing sites. New 5G spectrum options in the mid bands (around 3.5GHz) and in the high bands (such as the millimeter wave frequencies) present great opportunities with large bandwidths.

Operating with these new spectrum assets, the added RAN nodes can also use advanced hardware features such as an AAS to fully capitalize on the benefits of NR. The coverage provided by the low-band and mid-band spectrum assets is key to enable Critical IoT services in wide-area deployments. Adding network capacity over time will not only increase the capacity for eMBB, but also boost
the capacity for Critical IoT.

Case studies

To illustrate how 5G spectrum assets can be utilized for Critical IoT, we have put together case studies for two deployment scenarios: wide-area deployment and local-area deployment inside a factory.

The wide-area scenario is based on a macro-deployment in central London with an inter-site distance of approximately 450m, assuming low-band FDD, mid-band FDD and mid-band TDD spectrum options. For the mid-band deployments, we include an AAS, with eight antenna columns for 3.5GHz and four for 2GHz. Devices with four receiver branches are used in the evaluation.

The local factory setup is based on a factory automation scenario [15] and assumes mid-band and high-band TDD options. Table 1 lists the spectrum options chosen in the case studies.

Spectrum option Frequency allocation Deployment scenario Subcarrier spacing
Low-band FDD 2x10MHz @ 800MHz Wide area 15kHz
Mid-band FDD 2x20MHz @ 2GHz Wide area 15kHz
Mid-band TDD 50MHz @ 3.5GHz Wide area 30kHz
Mid-band TDD 100MHz @ 3.5GHz Local factory 30kHz
High-band TDD 400MHz @ 30GHz Local factory 120kHz

Table 1: Spectrum assets considered in the case studies

The top half of Figure 3 presents the served capacity per cell versus various reliability and round-trip RAN latency requirements for outdoor UEs in the central London wide-area deployment scenario. All the TDD cases assume a TDD pattern with 3:1 downlink (DL) and UL split. Observe the cost in terms of capacity when pushing for tighter reliability and latency requirements. Generally, a tighter reliability or latency requirement leads to a higher consumption of radio resources, as the scheduler needs to provision a larger link adaptation margin to reduce the likelihood of failures in the initial transmissions. Furthermore, we observe that the mid-band options can offer a significant capacity boost for the wide-area scenario, thanks to large available bandwidths and use of AAS.

Figure 3: Served capacity per cell versus various reliability and round-trip RAN latency requirements for the two scenarios

Figure 3: Served capacity per cell versus various reliability and round-trip RAN latency requirements for the two scenarios

Among the two mid-band options studied, FDD at 2GHz is attractive when greater UL coverage (99 percent) is desired. Our case studies also show that it is challenging for the wide-area deployment to provide full indoor UL Critical IoT coverage using mid-band spectrum options, due to building-penetration loss. In general, indoor coverage depends on building materials and building sizes.

Under favorable conditions, such as low-loss facades and limited building sizes (that is, less than 3,600sq m in footprint), it is feasible to have 95 percent indoor UL coverage even using the mid-band carriers, although the achievable capacity is limited. Local indoor deployments are a prerequisite in high-loss or very large buildings, and are also necessary in other buildings if high indoor coverage and capacity is desired.

Although suburban and rural scenarios typically have larger cells, it is nonetheless possible to achieve similar results there. This is because antennas in suburban and rural environments tend to be installed at a greater height, there are fewer obstacles and the smaller buildings result in less wall-penetration loss. These factors compensate for the differences in cell range, making it feasible to achieve very good Critical IoT performance in suburban and rural scenarios as well.

For local-area studies (scenario #2), the deployment using 3.5GHz spectrum is based on a single-cell deployment with eight antennas installed in the ceiling, uniformly distributed across the entire factory, and a DL and UL symmetric TDD pattern. For the high-band deployment, eight transmission points with full frequency reuse are considered. The 3GPP indoor factory channel model with dense clusters, including machinery, assembly lines, storage shelves and so on [16], is used. To achieve 2ms round-trip RAN latency, NR mini-slot and configured grant features are used. (Using the same features, an FDD carrier with 15kHz subcarrier spacing can also achieve similar latency.)

The bottom half of Figure 3 shows that both DL and UL traffic achieve 100 percent coverage. Tightening Critical IoT requirements reduces capacity, however, and this is more evident in the high-band case. For the mid-band case, all users consistently reach the highest spectral efficiency except for UL traffic with the most stringent requirements, due to good coverage and the absence of interference achieved by the single-cell distributed antenna deployment.

5G NR CA allows radio resources from multiple carriers in multiple bands to be pooled to serve a user. For example, DL traffic can be delivered using a mid-band carrier even when the UL service requirements are not attainable on that mid-band carrier, by using a low-band carrier for the UL control and data traffic. This allows the DL capacity of the mid-band carrier to be utilized to a greater extent.

In essence, inter-band CA allows an MNO to improve coverage, spectral efficiency and capacity by dynamically directing the traffic through the better carrier, depending on the operating condition, user location and use case requirements. With a low-band carrier, there are also benefits of pooling an FDD carrier and a TDD carrier from a latency point of view, using the FDD carrier to mitigate the extra alignment delay introduced on a TDD carrier due to the DL-UL pattern.

Deployment strategy

MNOs have started to upgrade some 4G LTE radio base station equipment to 5G NR through software upgrades. The dynamic spectrum sharing solution allows efficient coexistence of LTE and NR in the same spectrum band down to millisecond level [14].

MNOs can start to address time-critical use cases in the wide area (the entertainment, health care and education sectors, for example) by adding support for Critical IoT connectivity to the NR carriers through software upgrades. More stringent, time-critical requirements call for radio network densification, edge computing, and further distribution and duplication of core network functions, which can be done gradually over time, while maximizing returns on investment.

In the confined wide-area scenarios (railways, utilities, public transport and the like), relatively stringent requirements can be addressed with reasonable investments in existing and new infrastructure. In local-area scenarios such as factories, ports and mines, even extreme time-critical requirements can be supported once the E2E ecosystem is established.

Dedicated spectrum has been allocated to some industry sectors in certain regions. In the wide-area scenarios such as public safety and railways, the allocated bandwidths are typically small (10MHz or below) and unable to meet the capacity demands of emerging use cases, especially those with time-critical requirements.

In some regions, significant TDD spectrum has been allocated to enterprises for local use (in the order of 100MHz) in mid-band and millimeter-wave frequency ranges. For both confined wide-area and local-area scenarios, the reuse of MNOs’ existing infrastructure and their flexible spectrum assets (in combination with dedicated spectrum, if available) brings major value and opportunities. This approach makes it possible to exploit the full potential of various band combinations and support seamless mobility and interaction between public and dedicated communication infrastructure.

Conclusion

Critical Internet of Things connectivity addresses time-critical communication needs across various industries, enabling innovative services for consumers and enterprises. Mobile network operators are uniquely positioned to enable time-critical services with advanced 5G networks in a systematic and cost-effective way, taking full advantage of flexible spectrum assets, efficient reuse of existing footprint and flexible software-based network design.

References

  1. Ericsson Mobility Report, November 2019
  2. Ericsson white paper, Cellular IoT in the 5G era, February 2020
  3. 3GPP TR38.913, Study on Scenarios and Requirements for Next Generation Access Technologies, 2017 (zip)
  4. 5G-ACIA white paper, 5G for Automation in Industry – Primary use cases, functions and service requirements, July 2019 (pdf)
  5. Ericsson Consumer and IndustryLab Insight Report, A case study on automation in mining, June 2018
  6. GSMA, Cloud AR/VR Whitepaper, May 8, 2019
  7. Proceedings of the IEEE, vol. 107, Issue 2, pp. 325-349, Adaptive 5G Low-Latency Communication for Tactile Internet Services, February 2019, Sachs, J. et al.
  8. Ericsson Technology Review, Distributed cloud – a key enabler of automotive and industry 4.0 use cases, November 20, 2018, Boberg, C; Svensson, M; Kovács, B
  9. Academic Press, Cellular Internet of Things – From Massive Deployments to Critical 5G Applications,  October 2019, Liberg, O; Sundberg, M; Wang, E; Bergman, J; Sachs, J; Wikström, G
  10. NGMN white paper, 5G E2E Technology to Support Verticals' URLLC Requirements, November 18, 2019
  11. Ericsson Technology Review, Boosting smart manufacturing with 5G wireless connectivity, January 2019
  12. Ericsson Technology Review, 5G-TSN integration meets networking requirements for industrial automation, August 2019, Farkas, J; Varga, B; Miklós, G; Sachs; J
  13. 5G-ACIA, Exposure of 5G Capabilities for Connected Industries and Automation Applications (white paper), June 2020
  14. Ericsson Spectrum Sharing
  15. 3GPP TR 38.824, Study on physical layer enhancements for NR URLLC, 2019 (zip)
  16. 3GPP TR 38.901, Study on channel model for frequencies from 0.5 to 100 GHz, 2019 (zip)
